Docker Crash Course #5 - The Dockerfile

so then in the last lesson we talked briefly about how docker images are made up of different layers right and generally when we're making a new docker image our first layer is going to be some kind of parent image like the node one that we downloaded and then this parent image would normally be an operating system and something like node or python or php or ruby or something else entirely then on top of this initial layer we'd add our own extra layers which add more to the image or change the image so that's how you can think of layers as changes to the image that we're ultimately making for example we'd copy source code over to the image would install dependencies on the image and we'd store other information like commands inside the image as well but how do we do all this how do we actually create our own docker image with all of these different layers well it's pretty simple to do we just create something called a dockerfile which is like a set of instructions to docker to create the image and the dockerfile essentially lists out all of these different layers or instructions to create those layers on an image so now let's take a quick look at how to make a dockerfile and then use it to create a docker image now i've already got open a dummy application here in this api folder which you can find on the lesson 5 branch of the course files on github the link to that is going to be down below the video and this application is just a simple node app which uses express to create a very very very simple api so you can see right here in the app file that we have a simple express application set up and we're listening for requests on port 4000 and we have this handler function right here for this endpoint which is just basically the root endpoints so when a get request comes in to this endpoint then as a response we'll send this json data so like i said a really simple api but don't worry if you don't actually understand this code here it's not overly relevant to what we're about to do with docker it's just a dummy node application that we're going to create a docker image for and then eventually run it inside a container so this application also has dependencies that need to be installed for its work and those dependencies are listed inside the package. json file okay so you can see right here for example we have express as a dependency now normally if i wanted to run this application directly on my computer i'd first of all need to run npm install in this project directory so i'd open up a terminal and type npm install and that would install the project dependencies inside this project folder in a node modules folder and then after that to run the application i just type nodeapp. js which is the name of the file i want to run and that would start the application running directly on my computer and it would be using the node version that i have installed on my computer but we don't want to do that we want to run the application inside an isolated container with its own version of node running inside it so to do that we need to make an image and that image should contain the initial parent image layer to say what version of node and linux distribution we want the container to run and then after that the extra layers which will be to copy this source code and all the dependencies into it and then some extra information too and again the way we make this image is by first making a docker file so let's start now by making that docker file in the root of this project folder so the name of the dockerfile is just dockerfile with a capital d and no extension at the end of it i remember this dockerfile is like a set of instructions which tells docker how to create a specific image with all of its different layers and each instruction is going to be on a different line inside this file and generally speaking each line in a docker file kind of represents a different layer in our final image now before you start actually writing this out it might be a good idea to install the docker package for vs code so if you want to install that go to extensions and then just search for docker up here and it's this package right here so click install and you can read about it right here so install that first of all then we can start to write out this file so the first instruction the first layer of our image is going to be the parent image the node image that we can download from docker hub so this goes at the top of the file because it will be the first layer or the initial layer of the image that we want to create now to do this we simply write from in capital letters and then the name of the image that we want in our case that's going to be node and then a colon and say 17 hyphen alpine so what this line says is that to begin with we want to pull in the node image into our image as the initial layer so when we run this file later to create our image it will pull in the node image first of all and it's going to pull it either from the docker hub repository if we haven't already downloaded it or our own computer if we have now we downloaded a node image but it wasn't exactly this one it was kind of the default version of that image the latest one but this one now has this tag 17 hyphen alpine which means get version 17 of node and use the alpine distribution of linux all right so it's going to download this from docker hub so then that is our initial layer apparent image and to add a parent image like this as the initial layer remember we use the from keyword at the top of our docker file so then on top of this we also need to add our own additional layers now the next layer i want to add is to copy all of our source code into the image so this app.

js file and these json files as well and to do that we say copy and capital letters then a dot then a space then a dot again but what does this mean well first of all we say copy which means copy some files to the image and then the first dot is a relative path to the directory i want to copy my source files from and since those source files are in the same kind of root directory as the docker file then the path is just going to be a single dot which means the current directory if all my source code was in a source folder over here then instead of just a dot it would be dot and then forward slash source now the second dot is the path inside the image that i want to copy my source code to remember i said the images have their own folder structure so right now we just say dot which means copy into the root directory of the image that we're creating now a lot of the time we don't copy into the root directory because it might clash with other files or folders inside that root directory so instead we could say copy to a path which is forward slash app for example and then this would copy our source files into a new folder called app inside the image all right so the next layer of the image would be all the dependencies that we need to install on the image now to install dependencies into a project we'd run npm install and we can do a similar thing to the image that we make we're allowed to specify commands that we want to run in the image as the image gets built so at build time and to specify a command we'd use the run instruction now the command that we want to run is npm install which installs all the dependencies listed in the package. json file remember we copied that file over to the image in the previous layer so this run instruction right here tells docker to run a command on the image itself as this layer is being added on while the image is being built and so then all the project dependencies will be installed onto the image as well but there is one slight problem the command is going to be run inside the root directory of the image but our package. json file got copied to an app folder so that means that when this command gets run in the root folder of the image it won't see the package.

json file in that folder and therefore it won't install the dependencies so for this to work we need to run this command in the same directory as our package. json file so that's inside the app folder right and the way we do that is by specifying a working directory for the image so the way we do this is by adding a work dir which stands for work directory instruction to the dockerfile and i'm going to place this at the top just underneath the first instruction so that every instruction after this can use that working directory and for a value i'm just going to say forward slash app so what does this working directory do for us well it tells docker that when we run commands on the image in future after this instruction or if we specify paths inside the image to do it from this working directory so now when a command is run like this npm install it will do it from inside the app folder so that is one problem now solved but there is one other change that we need to quickly make now that we have this working directory it's the path that we want to copy to right here because this is now a path relative to that working directory which means that the source code will now get copied into forward slash app and then forward slash up again so to solve this we can just replace this with a single dot and that means copy it to the root directory relative remember to the working directory now and so now everything should work correctly so again we can specify a working directory so that any commands that we run or any paths that we specify after this instruction are done relative to this working directory now there is one more instruction i want to create and that's another command to actually run the application in the container now to run this node application we'd run the command normally node app. js in the terminal right so you might think that we just add another run instruction right here at the bottom to say node app.

js but we don't do that let's think about why not when we add a run instruction it runs a command as the image is being built so at build time and remember the image is not a running application it's just a blueprint for a container and the container is the thing that actually runs the application in other words it's a running instance of the image so it makes sense to use the run instruction for installing dependencies at build time onto the image as the image is being created and that way they're all included in the image and ready for when we run the container based on that image but it doesn't make sense to run the node app. js command build time because we're not trying to run the application when we're building the image we're just making the image right and instead we want to run the node app. js command when we have a running instance of the image inside the container so how do we specify this well instead of using the run instruction we use an instruction called cmd and cmd allows us to specify any commands that should be run at runtime when the container begins to run but the way we write this command is a little bit different we write the command as an array of strings in double quotes so the first one would be node and then the second one the second element would be app.

js and then when the container runs this command will be run right here which is node app. js and that is going to spin up our application inside the container all right so now there is one more thing i want to add to this docker file and that is an expose instruction which tells docker which port the container should expose because remember inside the app.
