Very good guys! Electrical Commands Course - Class 1. In this course, we will cover, in essence, what are Electrical Commands.
So, from basic to advanced how to understand and design Electrical Controls. Come with me! (music) Commands or triggers Both have the same meaning and purpose.
So if anyone talks about Electric Controls or Drves , they are basically talking about the same thing. The purpose of which is to turn on, turn off or even control an electrical device. On the right side of our monitor, if you notice, we have a single-phase motor drive with a direct start.
On the left side of our project, we have the drive. The Commands part. And on the right side we have the Power part.
The Power part, which is the Engine Charge part. (music) Let's do the division into three steps to make it easier to understand what Electric Commands are. Basically we have: Input devices and electrical signals.
Electrical signal processing devices. E Electrical signal output devices. (music) The input devices are the elements that have the basic purpose and functions: turning on, turning off and controlling the equipment.
How to order an advance, a retreat. Clockwise, counterclockwise, up, down, on, off, turn on one light, turn off another. The input devices then determine the information that will be critical to the Electrical Device's work .
(music) On the other hand, Electrical Signal Processing Devices are all elements that receive impulses, or even electrical signals, from Input Devices. They will process this information and then perform an action that results in the functioning of the Output Devices . These Processing Devices can be Analog Devices, Electromechanical Devices or even Digital Devices.
As Digital Control Boards, PLC's or Logic Controllers, such as Frequency Inverters, among others. So, Processing Device, there is a very wide range of Devices that will be covered in great detail a little further on. (music) And finally, we have the Output Devices.
They are all the equipment that will carry out, make the transformation of Electricity into work. In light, movement, finally. They are responsible for carrying out movements, lighting, or even industrial scale productions.
Your Output Device is based on your need or need to do something different. How to light, cut, push, ascend, descend. Anyway, the Output Devices are the most varied.
They meet the need to perform a certain job. That was the first class. We only present the concepts of what are Electrical Commands, Input Devices, Processing and Output Electrical Signals.
In the next class, we will cover in greater detail and practical examples of each of these devices. So, don't forget to subscribe to our Channel, activate notifications so you don't miss any of the content that will be presented here for free and with the highest quality. A big hug and see you in the next video.
Bye Bye! ! !
