The Only Unbreakable Law

Any time i'm giving a lecture to students one of the things that i'm always kind of afraid of and i think everyone should be is that students if they go on to a long programming career will be programming for like 40 years and i've already been programming for 40 years and i know that any kind of advice or information or things that people say are true 40 years ago often aren't true even a few years after let alone for all your entire programming career so for this lecture i kind of wanted to try and figure

out is there anything that i could say about software architecture which is primarily what i work on day to day and what i think most about is there anything i could say that i've ever seen that approximates an actual like law Like something i don't think will ever break so that if you learn to think about it and apply it every day in how you view software architecture and architecture in general that you'll never really have to update it maybe you'll refine it but you'll never really have to update it so first i want to

try and tell you what is a law like what do i actually consider a Law to be and we can look to other domains and figure this out really quickly we all know what a law is in physics here for example is newton's law of gravitation and this law is very simple it just says that the force acting between two bodies right is going to be proportional to some constant times the masses divided by the radius squared between them right the distance squared between them And this was very revolutionary i'm sure at the time it

was presented but it lasted for 400 years or some odd till today and we still use it if you wanted to do gravity simulation today in a program in like terrestrial body mechanics you would still use this until you got to like entire solar systems or something like that right so this law did get replaced eventually Got replaced by einstein's theory of relativity which i've never typed into a program i have used the old one um newton's newton's law i've never used einstein's sort of updated law and so to me that is really what the

definition of a law is it's something that we're so sure about like newton's law of gravitation that we've proven out so well that even when it turns out to be wrong it's not really wrong it's more like not Quite complete and we're sort of making some more subtle more nuanced version that lets us capture more things we don't even have to stop using the old one because it really does still work in all the places it wasn't a lie for all the things we were using it for it still works it's just now we want

to go beyond we you know make a refinement so the question is does software have anything like this right software is very new uh physics has been around for much longer So you expect them to have laws by now hopefully right but but what about software i would say that you know it's too early for us to say but there are things that do look like they might turn out to be laws for example this is omdahl's law it's actually called a law amdahl's law but in software people call everything a law so that's not

really much of an indication there's no criteria for being called a law but it does happen to be It's amdahl's law and this is a very interesting observation about parallelizing programs what it says is the time execution time like how long you expect something to run the time for something using n parallel workers so like n threads for example is going to be equal to has to be equal to the amount of time it takes to run the part that cannot be parallelized so the part that simply cannot be broken up into multiple work Pieces

that can be done simultaneously the part that cannot be paralyzed plus whatever is left over so the time it takes to do the thing single threaded minus the part that cannot be paralyzed divided by the number of threads now you don't have to understand this for the lecture so you know i'm not going to go into too much detail but it's a fairly simple equation and it's fairly straightforward if you went and looked at it for 10 Minutes you'd totally get it and if you graph what this means you can look this up anywhere i

grabbed this chart from wikipedia just a well-known result as you start to increase the number of threads so as you increase the number of computing components working on a task amdahl's law tells you that the amount of time it takes to execute that task rapidly approaches and then can never exceed The amount of time it takes to execute the single threaded part why because that part doesn't get faster by adding more threads and here you can see a couple lines one is for if it's a perfectly parallel parallelizable problem basically if 95 of it's paralyzable

versus if like very much smaller amounts or pellets you can see where you end up asymptotically on your speed up right and so you can see why this happens it's Very uh simple as the number of threads or parallel workers goes to infinity this term just drops out because the n becomes extremely large so it just isn't there so really it's just the non-parallelizable part that dominates the runtime so as you get more and more and more and more cores in a computer or more and more in course in a gpu or whatever it is

you expect the single threaded part to become dominant because it will never speed up no matter what we Do but of course that's not really about software architecture i mean it does tell you something about optimization and it might inform your choices of software architecture it is sort of something i think everyone should know and i do think it's good to learn will it stand the test of time who knows i mean we'll probably get more subtle versions of it people already are sort of thinking about communication in there More there's other things you would

probably add to it but it's a very good thing to know and it does seem kind of like a law because we know you'll never be able to exceed that asymptote no matter what you do that's just math but does architecture have any laws like that right that doesn't really tell us anything about the structure of the program beyond the fact that here's the speeds it will end up running at if you Broke it into this many pieces but that's really all it tells us so there are things going around masquerading as laws but they're

really not laws some of them are called law some of them aren't there's things like the you know if you googled software architectural law which i did just to see what people might call a law you'll get things like the pareto principle which is also called the 80 20 rule it's like you know it comes in various forms 80 of the time is spent in 20 of the program or other things like that there's all kinds of versions of it but it's not a law it doesn't really tell us anything it's also just kind of

not true i mean sometimes it happens sometimes it's not it's more of like a vague this tends to happen kind of a thing um that you know it like like maybe uh but you know not it's not even really actionable in all that many ways so it's it's not really a law Um you have things like solid which you'll get taught which are like this list of rules of thumb for object-oriented programming or something but again it's not a law doesn't tell you anything about software architecture other than some things someone thought was a good

idea most of which i don't even think are good ideas so it's definitely not a law it doesn't there's no there's nothing in here that like causes an actual You know real uh emergent property of software to be told right like a law would there's things like pastel's law which is now something called a law but it's not a law it's just again a rule of thumb it says something like you should be lenient in what you accept and stringent and what you output again not a law and then there's brooks law which actually is

a software law but again It's still not quite architecture but i do want to mention it because much like amdahl's law it's sort of a little bit related to what we're talking about here and it is something that appears to actually be true so i'm quickly going to say this before i go on to the actual i want to talk about brooke's law is an observation by fred brooks uh wrote the mythical man month a long time ago It was sort of the first book that said all these management practices are based on this concept

called the man month which imagines that a human being is just something that you throw at a problem and it gets faster so you know if we have something we're trying to make throwing more people at making it just makes it faster and what brooks tried to argue in this book was based on a lot of management experience and what the industry had Been going through at the time he basically tried to argue that look when tasks are complicated and they involve intercommunication you end up not being able to do that he these are graphs

that i grabbed from the actual book i happen to own this book and i scanned it the first graph is what it looks like when you add people to a project and they're no communication necessary so it's like they're just doing something On assembly line they don't need to talk to each other they just do it that looks a lot uh like what you expect right just keeps getting better as you go but you know each person you add you know the first person you add if you only have one person working something doubles the

time the next one won't you right so you have a natural sort of powerful off there uh the next graph is what happens if there's no ability to parallelize things If the things have to be done sequentially and they're you're only building one of them for example then adding people to a project doesn't do anything they're just sitting around doing nothing right because one person has to finish all the stuff they were doing and hand it to the next person before the work can proceed so you don't expect any speed up in that kind of

a case the asymptotic case which is the one on The right is the one where it says look you can make things faster by adding people but there's a communication barrier those people have to talk to each other in these complex tasks so rather than it continuing to go towards zero it's going to go towards something higher than zero that's whatever the natural communication cost is to coordinate this task they're never going to get beyond that not until we have hive mind Technology from you know elon musk implants in our peds or something like this

right and then finally he showed a graph that was like the worst case is when the communication cost actually can just increase past the efficiency point so if we add people to a project and our communication isn't efficient it will actually start costing more than it did originally as we add people right now if you take a look at the asymptotic One where it's like assuming we got our communication worked out as well as we could we assume there's a natural barrier where even if we're as optimal with communication as we can be we're going

to hit some natural floor if you just imagined like turning that around and comparing it to amdahl's law you're really kind of looking at roughly the same statement these are statements about how fast you can make something with parallel workers and recognizing That there's a fundamental stumbling block in amdahl's law's case it's the part that cannot be parallelized the part that has to be sequential and in brook's law case it is the part that it requires coordination between workers which makes it so that adding more does not get you as much as you would have

expected right now we're getting close because that sort of is about architecture but it's Not quite architecture yet so that brings us to the paper i actually want to talk about talk about which is how do committees invent this is a paper from 1968 in a magazine called datamation it was published in this magazine which by the way still exists which is which is odd it doesn't exist in print anymore it exists online datamation is a magazine where this was printed because the harvard business Review or something like this wouldn't print it because they didn't

think it proved its conclusions strenuously enough or something like that which is kind of amusing to me because this is probably one of the best papers on architecture i've ever read bar none so it's i guess fitting in my opinion of harvard business review that it didn't publish it so it was published by a fellow named melvin conway he was from caltech and he was actually Working at sperry rand on the univac at the time on rand's univac division okay so let me give you a quick overview of what this paper says and then we'll

kind of go into why i think it's important so this paper is very accessible i highly recommend that anyone who's interested in this after hearing the lecture go read it it is not a paper that requires a lot of technical acumen to understand it's it's broad it's Intuitive and it's very well written so it's other than the fact that it's kind of a little old-timey because it was 1968 so you know the the prose is a little more like sophisticated than it would be today let's say um other than that it's very easy to understand

what's being said what this paper says is there used to be you know inventors and they would just invent things right because the things They were inventing were pretty simple they could be invented and designed by one person or two people five people they could just be in a room doing stuff and then you got whatever came out the other end it was fine right but as we want to do things that are more complicated like the you know apollo moon landing these huge projects or even things that are less impressive like just a basic

computer still requires tons of people to work on These projects because they're that ambitious now and there's things that no one person can really hope to accomplish by themselves so in order to actually do the task of design of invention you must first do things before you start really and what the paper points out is before you even really get going somebody has to decide two things one what is it that we're actually making Meaning it can't really be very open-ended we have to first kind of circumscribe what we might be trying to make and

give it some kind of at least vague definition and then we have to decide what the structure is of the organization that will pursue that design right in other words we're going to need some way of we need a company right we need We need people in positions or a collection of companies or a consortium or committees or something if we want to bring more than 20 30 40 people to bear on this task we have to start breaking them into groups and at the outset someone's going to have to decide that or some small

group of people decide that the paper then goes on to say well if you're going to break things up right if you're going to have enough people That you have to start making teams that are going to focus on particular topics you've created a coordination problem right you now have to have those teams talk to each other they need to know what each other are doing and they need to be able to work with each other and that's an actual problem in and of itself separate from the act of inventing or designing whatever it is

that they're making and here Begins the very crucial and what i think are profound insights from this paper melvin conway then tells us once you have chosen some aspects of the design and you decide to delegate duties to it right like you create an org chart or something this team's going to do something and maybe that team actually needs sub teams to coordinate right once you start having a structure an actual human structure to the design Every time you make a new piece a new breakdown of that organization you are pre-supposing that certain designs are

not necessary you may not be doing this knowingly but just the act of drawing a dividing line between two teams means that you're saying that the design of the thing you're making doesn't really need to have a high bandwidth communication On between those two areas right like the tires of the car and the engine of the car are going to be designed by different teams so we're presupposing that the engine and the tire cannot be one piece right and sometimes that's a perfectly reasonable thing but other times it may be lopping off parts of the

design space that actually were where the best thing was Right so this leads to what i think is a really great conclusion probably the most important part of the paper although it's not the one it's remembered most for and that is that given any design team like this is the organization of the team you can Already say that there are certain designs it cannot produce because it is unable to do the communication that would be necessary at the frequency that it would need to do so to produce that design now uh if you take this

a little bit further and conway does in the paper what he basically says is that sets up a sort of homomorphism if we look at the org chart for an Organization and we look at the structure of the products that it produces we would expect them to basically just be collapses of each other meaning if i took one graph and the other graph i should be able to do some small node collapses or expansions on one or the other and get the same graph back there's going to be basically the same structure between the two

of them And we're not going to expect to see much difference okay so what this tells us is that we would expect to see right organizations only able to succeed at designing things that look like themselves and furthermore that if an organization cannot itself change its org chart meaning to the extent that it is Difficult in an organization to change how teams are organized or if you do so only very infrequently or if there's a lot of rules about who can talk to who et cetera et cetera you will cave off more and more and

more of the possible designs that you could have to the point where a completely static org chart one that cannot change one that has very defined lines of communication for example and it doesn't change over time Basically he comes to the conclusion that it will just produce a copy of itself every product that comes out of that org will just look like the org right so that's conway's law conway's law as pithily stated is that companies organizations teams at any level of detail they produce things that have the same structure as they do right it's

not so much that we're creating a piece of software as we are Creating a copy of ourselves in software right with the same kind of diagrammatical structure so to put this a little bit more visual for those of you who've never had any experience with comedy's law before which is probably a lot of people because it doesn't get talked about that often so not many people have really thought that much about it unfortunately uh hopefully that will change because i Think it's very important but if you imagine us sitting down we're gonna design something first

we have to decide what we're going to design all right maybe we decide we're going to design an operating system and then we start to come up with the things that it needs oh it's going to have to have like internet and it's going to have to have this and that and like one of the things we decide is Going to need is media like it needs to play back media it has to have like audio visuals right so we decided there's going to be like a delegation from you know the the main you know

our main company there's going to be a team in there or probably an org a whole sub org devoted to figuring out how this thing is going to play media and writing that well probably because we're hiring people we're going to hire like audio people For audio and video people for video we probably end up structuring the team as there's an audio team and a video team right and they're both underneath the media umbrella the audio team might be like split up into like playing music versus playing sound because some of those have different uh

you know aspects to them or whatever uh and then the video team might be like split into 2d and 3d let's say this is this is just give you a very Simple example of like very basic any org chart today like at a company um like google or something is vastly more complicated than this so this is like very simple background just to give you a flavor of it right if we were to sit down and do this what would we expect to see as a product at the end of the day it would not

be something that's just arbitrary we wouldn't expect to have i don't know there'll be some api for playing media i Don't know what it will be or it'll just be an operating system that happens to be able to play media no what we expect to see is this direct music direct sound direct draw direct 3d right we expect to see one api for each of these things because that is how we structured our teams we decided ahead of time that that's what we were going to do and so the product has that structure and by

the way this is exactly the structure that windows had when they Sat down to do this right now furthermore they also ended up with other parts of the org chart exposed we not only know as end users who were not privy to design process we not only know about the fact that there was this direct blah in here but the directx org like the whole system that works on that also kind of gave itself a brand and has its own like sdk that they ship right so the the whole org chart actually starts to be

exposed And we can see it in the end product now there's an additional wrinkle here that i want to talk about a little bit later so i'm just going to you know put it in there so that way i can come back to it and that is if you look at what ends up happening nowadays these are a little bit different direct music went away it's not still there you can still redistribute if you wanted to use it or something but it's not like actively Pushed and the org doesn't exist inside microsoft anymore it went

away in both the product and the company right there's x audio now instead of direct uh instead of direct audio right that the they they've added new ones the old ones are still in the product but there isn't like a team working on direct direct sound sorry um i meant direct sound not direct audio so it's right in the slide i said it wrong uh x audio direct uh draw is now direct 2d but it's a completely different api right so direct draw is still in there but direct2d is there now as a different api

and direct3d is still around that one has maintained the whole time so again don't need to think about that part right now but we're going to come back to it so please remember that you know when you first create one of these things in software that's not the end of the story Okay so what i want to try and get across here is that what conway's law tells us if it does turn out to be true is that the org chart is the asymptote right at the end of the day the best you can do

is put out a product that looks roughly like the org chart now it's an asymptote it's the best you can do the worst you can do is actually something much more uh You know granular like something where we have lots of different apis or things for one purpose because a team that didn't really have to didn't do a very good job so they make too much complexity in their area and don't do a good job on their design let's say so it's an asymptote it's the best we can do it's not necessarily what we'll get

because maybe the people weren't very good or maybe it's our first time around or whatever who knows But it's the best we can expect to do now if it's an asymptote to me it fits nicely in here right we had brook's law we had amdahl's law and now we also have conway's law and they're all talking about asymptotes in what we can aspire to do in programming brook's law tells us the asymptote for like getting a project done right it's about the inter team communication it Tells us what we can expect from our schedule omdahl's

law tells us what we can expect for when the thing runs because it's just going to tell us no matter how fast computers get there's going to be this natural asymptote based on what we see in the unparalyzable part of our program the longest single dependency chain if you will and then we have conway which tells us at the limit if we do the best we Possibly can what will the software architecture of our product look like and the answer is it will look like the teams and communication structures that built it now i want

to emphasize that the y in conway's law is way more important than the what because the y can be applied all over the place so just remembering the pithy saying of org charts produce copies of themselves doesn't really give You the full insight and so what i want to do is just emphasize i just like to make it really clear for anyone who wants to sort of get this into their brain as a fundamental tool that what we're talking about is not org charts necessarily cloning themselves that's the result but the mechanism for that has

to be understood the mechanism is That communication between teams is more costly than communication inside teams or if you want to go to the limit a single person typing in code communicates with themselves basically infinitely fast i always know what i am thinking right so one person has complete latitude to think their way through a problem any way they want to as soon as i split that problem into work that two people have to do there now has to be some communication between Them either they agree on an interface or they communicate daily or weekly

or monthly to update how their code will work with each other right or they don't communicate at all which means that their code cannot co-evolve meaning the boundary between them will remain fixed at all times because there's no way they can even talk to each other and uh you know have some kind of a way of agreeing on what to do next um and again communication this Case doesn't mean literally talking it could mean that i check in something to a source tree that you have to check out right and that always costs way more

than if i were just doing it because you don't know what i was thinking you don't know why i did these changes you don't even know if they're good or whatever right you have to validate that or come to an understanding or ask me so no matter what ends up happening The higher the cost of communication the less iteration will happen there so what you end up with the reason that org charts seem to replicate themselves is not because of that literal concept that org charts replicate themselves it's because inside any given organizational box communication

is faster and therefore design iteration can happen more quickly than if it has to go across boxes where The cost is increased so it's really about creating nested domains of optimization where each level you go down the design can be optimized more fluidly and more quickly and each level up you go each time you try to go further like for example if i needed this team here to talk to that team there they have to go like all the way up and over here if there isn't a way for those two teams to meet directly

for example right The further the path is between two things the less we would expect them to be able to explore shared design where solutions to their problems actually come from doing work together right so conway's law is not only about org charts it's actually just about this fundamental concept that there are high cost and low cost areas and the low cost areas will get optimized eventually if you have good people but the high cost Areas cannot be they just can't be so what i'd like to do finally is take a look at where we've

gotten to now today if you believe anything that i just said about conway's law or maybe i should say if you believe conway's paper and i highly recommend everyone read it i don't think we can call it a law yet because we don't have lots of ways of proving things in the software world and we don't really know how to come to that Kind of consensus so it's called conway's law i kind of think it probably is sort of a law but it's not the law like law of gravitation but it's the only thing i

could think of that might someday be and furthermore i would say i can already sort of see that there's also probably an einsteinian refinement to it right there's probably going to be if we can really confirm conway's law as some kind of actual fundamental property that We would then also see that there's a refinement to it that actually carries extra nuance so that's what i want to talk about now i call this section conway's nightmare because i wanted to call the talk that but unfortunately melvin conway is not the con way people think about usually

about john conway so i thought if i called the talk conway's nightmare people would come thinking that there was going to be a lecture on john comey Which is not and i didn't want to be misleading so i figured mysterious title is better than misleading title and i went with the only one unbreakable law if you would like to mentally re-title this conway's nightmare please do okay it's not that conway didn't know about software architecture he did so i'm not trying to say that conway Didn't already think about these things i'm just pretty sure that

he didn't quite foresee where things would go because he was writing this in 1968 when software and software creation organizations were much simpler and smaller than they are today conway definitely knew about software he gives an example in the paper of assigning five people to write a compiler and getting back a five pass Compiler right um which is kind of funny but you know is exactly kind of what you would expect right he also gives an example of an operating system being broken down into the same parts as the orgs that actually designed it right

and things like this so he was thinking about computers and software for sure when he wrote the paper but i don't think he was thinking about anything like this right nowadays some of the most important and Foundational software that we use every day like unix or something or windows you know their lifespans are massive the original code branch of windows is 1985 to 2000 right that got merged together to produce like with the windows and t code branch was started in 93 these kind of merge together and are still running today in 2022 right so

we have something that started at least part of it in 1985 and that's Running until 2022 and beyond there's no sign that anyone's going to stop running windows next year right so that's four decades of a code base being in use there are some ideas probably from the original version of windows some small pieces of that design concept space are probably still present today certainly all the ones from windows 95 Era are there still today right uh the entire ui basis if you actually look at the programming model looks like that right it's maybe slowly

getting replaced over the years but it's still all there and tons of things use it etc etc so four decades 40 years right of codebase and so what i think conway didn't foresee because i don't know how he Could have but what conway i don't think foresaw is he was thinking that there would be like a company org chart that's going to make a product and they make the product and it looks like the org chart right so company makes product they look like each other and then if you change the org chart to something

somewhat different you made some changes the next time you make a product it will Then look like that org chart i think that's what conway had in his head when he was thinking about this paper right we changed the org chart we change the product what i don't think he foresaw is that these products because software is so easy to leave around nowadays legacy code bases are not just common they're like the rule when you do your next product it's more like the Previous product also carries forward right so new products not only have the

org chart from the old team and the new team like in in them they merge right so a product you produce today will effectively have something in it from like every org chart your company ever had will be in your current design at least that's what it appears to be doing as Far as i can see right and the only time this stops happening is if you do a clean wipe if you say we're getting rid of all of this code and we're starting over or something like that right it says if you became a

new product or a new org and that's what i think kama was thinking of i don't think he was thinking that things would end up mostly being like this he probably would have thought of this as like a rarer case but Now it's the norm so what that means is those delegations those breaking things down and introducing barriers because you have to for communication now includes time travel we're not just talking about one org chart we're talking about all of the superpositions of all of the org charts that existed in time much like an einsteinian

modification to newton's law of gravitation time is on the table now right And just to give you some example if you don't believe me um i i have my operating system workshop before let's you know say we're doing microsoft windows it has that audio team somewhere in there and you know that's the kernel audio team i said that that was just the directx one that i drew but really the org chart for windows is way more complicated because there's audio driver teams like the kernel audio which is different than the Directx audio team like it's

there's a whole situation right but let's assume we're just talking about we want a volume control on in our audio right so we have some audio organization who knows how complicated it is probably very if it's microsoft or something and just somebody gets assigned the task or even a team gets assigned the task of please be able to control the volume of this Like the speakers right i just i i just need the volume of the speakers i want to be able to turn this volume up and down so what we would expect based on

conway's law as an asymptote if everyone's doing their job is there'd be a volume slider somewhere and maybe for usability purposes that volume slider could pop up in multiple places but we would expect it to probably be all the same volume slider because the person Would figure out okay what's the best way to display volume and they would just display the volume that way and you the user would learn to use it once and then they would always use the volume slider and understand it and it would be predictable and they would they would know

it by sight and all those great things and they would have a clear understanding that it was the same volume slider all of these things should be relatively easy to accomplish it's One slider for one value right but what we actually see if we open up windows this is on my personal machine i just screenshotted all the volume controls that are on the base install of windows this is how many you have there's actually five so you don't just have one volume slider you actually have five volume sliders and they're not just five copies of

the Same slider that are popped up for convenience they're actually all like completely different some of them are horizontal some of them are vertical some of them include a picker for whether or not you're going to change the output some of them don't some of them have additional settings buttons or other things like that some of them have a mute button you know all these there's there's all of these different things that might be involved or might not be Involved depending on the circumstances right and if you take a look at where all these come

from what's interesting to see is that none of them come from the same version of windows basically some of this comes from like the original control panel some of this comes from windows 7 adding a more sophisticated mixer drop down i believe it was windows 7 it could have been xp or vista i i to be honest i i Don't really have enough version of windows to check but then there was windows 8 which added a modern settings experience as they call it it's definitely experience windows 8 added a modern settings thing and that has

its own kind of different style in there um and then in windows 8 they didn't actually replace the drop down in the systray Uh with one that looked like it so it actually used to look more like this one when the drop down and the system the mixer from wind 7 is what you used to actually see but then in windows 10 they changed it to look more like the modern settings right so now when you run windows 10 what you will see is four volume sliders from windows and one that is actually predicted by

Conway's law directly now first let's talk about the conway's law predicted one so we need no modification to conway's law to realize that i made an error when i originally said well we have an audio team and we delegate to having a volume control so we would expect to have one volume control wrong i forgot to say well i mean i didn't forget because i made the slides i pretended to forget to say That we know there'll also be people shipping the sound hardware and the way that we chose to set up our operating system

way back when in windows is that the people who install the hardware can also install their own software and obviously if you have an org chart that has an audio team on one company microsoft and an audio team at another company which is the people who spy the sound card they're both going to delegate volume control to somebody and Those two teams are never going to talk to each other so we're going to have at least two volume controls in windows always for all of time they're at least b2 volume controls until they change this

idea right and lo and behold that's exactly what we always see in windows at least there's always the windows volume controls that they ship and then every ihv real tech you know whoever it is that you have for your sound your machine ships their own Thing which has its own volume control always right so that's just that's just going to happen conway tells us that will happen and he's always right in this case right but let's just focus on the windows part why are there four of these in the windows part when conway might have

said there'd only be one right because it's just one delegation to to one person or one team Well the reason is because of that temporal right delegation people write stuff in the original version of windows or you know windows 95 or something like this whatever the last time was that they did a wipe of that area and did a clean rewrite when they did that they introduced like this control panel which had a volume slider for you know the particular piece of you know the software that had a volume slider for that particular output Or

whatever it was in the control panel and later they decided well pop-up mixer would be better so at some point they add the mixer and that mixer also has a drop-down in the systray right that's that's a quick version that's a simple version of itself right then later they add the modern settings panel which is completely different thing and again they don't replace any of this and then finally they decide well we're Going to replace just the drop down so this old drop down is not going to be there anymore but they didn't bother to

replace the mixer so it's still there right so if we look at the different pieces of you know this software stack if you will when they got added and who was touching what when you can see that we actually have different pieces of the software being done at different times there was the Original programming org that was involved in doing this part there was the win7 org then the win8 org the win10 org and part of it is no longer visible right the win 8 part is not visible anymore because win 10 kind of unified

that whole thing right so we now are kind of seeing the win 10 result the win 7 result and the original result we're seeing at least three results right And when the user looks back at it they will see at least that many now in the original i was like well you kind of see this part that got introduced in win8 but it's sort of unified with the win10 part so that's why i didn't include it here so i'm giving them the best case the best case is you could say well it was it's win

10 control so it was reduced to win 8 but they're the same right so the win 10 control is basically the same we'll give Them that but the win 7 control is clearly different and the original control is also clearly different right so what we come to is that this org chart is not really the org chart that produced the software that we're talking about because this part of the org chart here this volume where we delegated the audio team delegated someone to write the volume they actually delegated only a subset of the code necessary

to do volume control in windows according to What actually shipped previous teams that existed previously in time were effectively delegated to for parts of the product that still ship today because it just continues as you ship the same code so this is the most generous interpretation of that org chart that we have a volume team that's actually comprised of three temporally distinct teams right so the reason we have at least four Volume control visual volume controls in windows is because of this right there are four actual teams working on it what we actually might say

is it probably looks more like this which is to say you would have to go backwards in time to actually communicate with the win 7 team or the original team so really it's infinitely expensive these links almost don't really exist so you would expect them to be completely separate and have no way of really Playing nice with each other or doing anything like that because the only choice for this team is basically to obey whatever these teams feed forward right if that makes sense so that's one reason i think conway's law is almost under selling

itself when it says oh the org chart brews a copy of itself really it's the entire temporal integration of the org chart that copies itself so it's this it's this Four-dimensional org chart that's replicating itself in the software today because the cost for just reshipping all the old software is very low so anytime someone doesn't have enough people to actually solve the whole problem they just leave all the old stuff in place so that they only have to just solve the new problem right and you just end up with this org propagation now there's another

problem which is that Programmers now think delegation is a separate good this is something that conway probably would not have expected uh necessarily in software but he actually did predict it in terms of management so i guess i would say probably somewhere along the line conway would have known this if he didn't know when he wrote the paper he would have said ah it looks like this is happening inside software as well so what i mean by that is What is this this is a class diagram of just the llvm operator class so like when

you want to add two numbers together or shift left or something in c right it's just the operator class just the operator class i'm going to keep saying that because this is just the operator class there's no code here this is just boilerplate that people Have to deal with and write down to basically specify like oh the operator you know goes to conditional operator has a shift left operate it's just code organization inside the code that does not specify anything about how the program runs it's just there as something that programmers added to artificially constrain

the way the program works that's what inheritance hierarchy is it's an artificial Constraint on how your program is going to work now if you turn this around right if you turn it 90 degrees it's an org chart so modern-day programming practices have actually now grown to effectively be org charts inside org charts there's an actual org chart which will replicate itself onto the product that is the organization of the humans that made it then there's an additional org chart That programmers invent for no reason other than they are unable to keep the entire complexity of

the problem in their head so they invent artificial breakdowns of problems that have nothing to do with the design process because the optimal design process would allow all of this to be fluid to find what design was best for the product as it goes they artificially fix and create increased cost to that change by Creating one of these for no reason other than mentally trying to grapple with the problem now unfortunately they don't really recognize that they're doing this because they've been taught that this is good this is a good thing to do it's actually

not a good thing to do it's a bad thing to do for the code the reason that it ever got a reputation for being good is because it is a way of breaking down problems to make them more Manageable so it may have been a necessity for a problem too large for the person trying to tackle it right but it was exactly what an org chart is in the real world it's something we do because we had to not something that's actually good this is a sign that you're under achieving not that you're doing a

good job you may still have to do it because we can't figure out how to do it any better given the human brain being what it is But it shouldn't be cause for celebration right now conway because this paper is amazing basically predicted all of this just more to do with management than software but he either was thinking about software or would probably soon think about software as also having these traits as he saw things happen like object-oriented programming coming along and so one of the things he says is if a designer is faced with

a problem That is too complex for the designer to solve what they will generally try to do is artificially break it up into smaller problems right and oftentimes they will do this without the necessary information about where those should happen right because by definition the person doesn't understand the problem that well so they're not necessarily able to figure out oh the end design should look something like This so i can break the teams into these pieces to tackle these problems separately and i won't incur any design costs because i already know that the end design

should be optimally looking like that so that's how you get these kinds of programming things happening and these kinds of situations where code bases seem to be divided in ways that doesn't actually make them very easy to work with because hey they probably were not Originally divided into that way by someone who actually knew what a good efficient end solution was because in order to start the process of programming they had to make decisions about design dividing things and in so doing they eliminated possibilities of the design space now things are only getting worse unfortunately

libraries engines package managers containers virtual machines Microservices all of these things are ways of introducing more org charts right more boundaries between things that cannot be optimized across because the people cannot communicate with each other rapidly or at all and again when people say that any of this is good it's very important to recognize it is not good right objectively speaking for the end product These are all bad because every single one of these implies that we are under optimizing our eventual product because we have a priority decided what we will not consider to work

together and to optimize together and to merge right we may need to do all of these things we simply might not have the brain capacity as humans or be able to form the kinds of communication structures that we need To until we have the elon musk brain implant right to do away with them so the we may be stuck with this but it's crucial to always keep our eye on the fact that it's not good that we do that people think these are good they're all bad right but we have to do them right now

because we haven't figured out how to do it better and it's crucial to keep that in mind because we might be able to do Better so we should always be on the lookout of ways we can stop doing some of these or doing them less because we would lead to more optimal products better design more efficiency now finally conway even predicted all of those things right he talks about the fact that managers when faced with a thing to do if they have the choice of trying something new and possibly it failing or going with some

old thing that they know will not Be as good of a fit for what they're doing but at least it's known quantity they'll go with the known quantity why because no one ever got fired for mitigating risk right so in terms of your success as a programmer or your success and management career unless you want to be a trailblazer right and you're like i'm going to blaze new i'm going to forge new paths of course you're going to do things like Yeah yeah i install as many package managers as i can and use tons of

libraries why because i know those things at least work because everyone's using them so i know i'll only be as bad as everyone else is right not somehow worse because i failed to do my new thing that would be more optimal or better right you're not taking that risk you're letting someone else take that risk because that's the safe choice so in conclusion Um i i would leave you with what with what melvin conway actually wrote he basically said that look if we care about doing a good job and we're trying to push our design

ability forward then what we need to do is understand that we must be as lean and as flexible as possible and as hopefully i've given you some indication of if you study this kind of thing you will realize that that goes For the org chart and the code base so both are actual communication restrictions that we have because we are humans we have to talk to each other and also the things we do in code that restrict its ability to be optimized together such as encapsulation or using a library those sorts of things normally considered

good actually they are all costs that lead to worse designs if we somehow magically could get past Them maybe our brains can't but if we could it would be better conway's law tells us so and i think it's really true and unfortunately those two things lean and flexible are like the opposite of what almost anyone's doing now 40 000 person orgs using hundreds of thousands of different components and libraries and docker containers inside virtual machines running on top of hypervisor like we're the opposite of Lean and flexible we are as fat and unflexible as you

could possibly imagine and it's kind of unfortunate and i think conway's law kind of gives us a lens to see why we shouldn't be happy about that maybe we're struggling to do better and can't but we should be struggling to do better in kant not thinking that we're doing good because conway's law kind of tells us that we aren't And so in closing i guess i would say all the thanks go to mr melvin conway for what is arguably the best software architecture paper i've ever read and in fact is just seems to be true

about architecture in general software or anything else and i'm i'm sorry on behalf of all of us working today that even though you warned us and gave us a lens through which to understand What we were doing wrong we still have sort of ended up in your nightmare scenario where all of those problems that you talked about are not only as bad as they were when you talked about them but they are ten hundreds thousands of times worse because we're really not doing a lot of work to try and get past them
